Full Function Matrix Remix With Low Lantency 12X12 Professional Network Audio System Audio Matrxi Mixer DSP
|
|
| Description: The MX-1212D audio processor is a freely designed audio processing and control system.It adopts advanced DSP processing technology, has a new automatic mixing, Feedback elimination, etc, targeted to solve various practical problems in the application scene. | Main Features: - USB Background music playback and recording function
- Support mobile phone, tablet control and distributed cloud control
- DSP audio processing, built-in automatic mixer, feedback elimination(AFC), echo elimination(AEC), noise elimination (ANC) function
- Input per channel:Front stage amplifier, signal generator, expander, compressor, 5 stage parameter equalization
- Output per channel:31 Section diagram equalizer, delay device, frequency divider, limiter
- Full function matrix remix
- Built-in automatic camera tracking function
- Support for scenario presets；
- Automatic memory protection when power off
- 1U Whole aluminum chassis
- Built in Dante Module
|
Specification:
| Model No. | MX-1212D | | DSP Processing | Ti 456MHz FLOPS DSP | | Number of analog channels | 12 Input + 12Output | | Number of Dante channels | 12 Input + 12 Output | | Core Algorithm | Automatic mixing, feedback elimination(AFC), echo elimination(AEC), noise elimination(ANC) | | GPIO | 8 ( Including input and output) | | RS232/RS485 | 1 | | RJ45 control interface | 1 | | USB Port | 1 | | RJ11 phone interface | 0 | | DANTE network interface | 2 | | Simulated maximum gain | 51dB | | Digitalizing bit | 24bit | | Sampling Rate | 48k | | Frequency Response(20~20KHz) | ±0.2dB | | Analog-to-digital dynamic range (A-weighted) | 114dB | | Digital-to-analog dynamic range (A-weighted) | 120dB | | Input to output dynamic range | 108dB | | Total harmonic distortion + noise | ＜0.003% @1KHz ,4dBu | | Floor noise (A- weighted) | -90dBu | | Delay storage | 2s | | Analog input to output system delay | 3ms | | Input impedance (balance -type) | 20KΩ | | Output impedance (balance -type) | 100Ω | | Maximum Input Level | +18dBu,balance | | Maximum Output Level | +18dBu,balance | | Equivalent input noise EIN(20-20kHz,A-weighted). | ≤-131dBU | | Phantom power (per input) | 48V | | Input common mode rejection,60Hz | 70dB | | Channel Isolation,1kHz | 104dB | | Dimensions (W*D*H) | 482*258*45(mm) | | Weight | 3Kg | | Power Consumption | <40W | | Operating Temperature | -10 - 50℃ | | Working Power Supply | AC110V-220V,50Hz/60Hz | |
Other Dante products:
- Dante DSP
- 2CH Dante AVIO
- 2CH Dante Wall Plate
- 4CH Dante Box
- 8CH,16CH Dante Interface
- Dante Speaker Management Processor
- Dante Speaker
- Dante microphone
- Dante DSP amplifier
Open web page and download the software :
Open the browser access to the IP address of the processor in the client host and enter the following page:
Click on the download button in this page to download the software for WINDOWS and according to the prompts to install.
Note: before installing the client software, please make sure your WINDOWS has been installed at Microsoft.Net Framework 3.5 or above. Part of the system (such as windows 8,it will prompt: "user account control information"), please click "ok" to enhance the software permissions
Client software login
After client software installation is completed, open the software, click the search button, and view the IP list of current network devices. Double click to connect the device's IP address, in the pop-up box enter the user name and password (the default user name: admin / password: 123456) and submitted, after landing successfully, the corresponding IP address bar will be changed into green by red.
FAQ:
Q1: Are you manufacturer or trade company?
A: We are manufacturer,which located in Shenzhen, Guangdong, China.
Q2: Do you offer OEM&ODM service?
A: Yes, We can provide OEM or ODM Solution depends on client requirements
Q3: What's the quality standard of your products?
A: Our products has approved CE, ROHS certification.
Q4: Which place will use FHB equipment?
A: Our products are widely used in International Conference, Governments, Banks, Churches, Airports, Parliaments, Education institutes, Hotel, Private corporate conference hall etc,.
Q5: What’s the delivery time?
A:Sample order: During 5days,Bulk order:10-15days
